What is an operator?

Multigres is deployed using a Kubernetes operator. An operator is a Kubernetes controller that runs inside your cluster and manages the lifecycle of a complex application on your behalf. Instead of manually applying configuration changes, scaling resources, or handling failures, you declare the state you want and the operator continuously works to make it so.

The Multigres operator is what turns a single YAML declaration into a fully orchestrated, multi-zone Postgres cluster.

What the operator manages

The operator manages pods — the individual containers running each component — directly, rather than delegating to Kubernetes StatefulSets. This means it can be primary-aware: it knows which pod holds the active Postgres primary at any given moment.

Primary-awareness ensures the operator always acts on standbys first and the primary last when restarting pods for a config change or scaling event, guaranteeing safe operations without interrupting writes.

A Multigres cluster is made up of several components that work together across availability zones. The operator provisions all of the following from a single MultigresCluster manifest:

• GlobalTopoServer — A managed etcd cluster that records topology state: which databases exist, which cells they live in, and where every component is registered. In a multi-zone deployment, the topology splits into a global server for cluster-wide state and per-cell servers for local discovery, so a partitioned cell keeps operating against its own local view.
• Multiadmin — The management plane for the cluster, including a web UI.
• Multigateway — Speaks the Postgres wire protocol. Applications connect to a gateway, which forwards queries to the right Multipooler over gRPC. Adding more gateways scales connection capacity horizontally.
• Multiorch — The orchestrator. One set of Multiorch instances per shard, running across cells. Watches replication health, appoints leaders through a consensus protocol, runs failovers, and coordinates bootstrap. When you apply the manifest, Multiorch runs bootstrap as a consensus-backed election — the same code path as every later failover — so there is no separate provisioning script that can race with itself.
• Pools — The Postgres pods themselves, managed by pgctld (which owns the local Postgres process) and Multipooler (which owns the connection pool). One pooler per Postgres instance.

Prerequisites

Before deploying a Multigres cluster on AWS EKS, ensure the following are in place:

• AWS CLI v2 — installed and configured
• kubectl — configured for the target EKS cluster
• Permissions — to create namespaces, CRDs, pods, services, PVCs, secrets, and to install the Multigres operator

Getting Started on EKS

This guide does not cover creating an EKS cluster, installing the AWS CLI, or configuring IAM from scratch.

Deployment Shape

Multigres can run on a single Availability Zone or across multiple Availability Zones, as long as the cluster satisfies the minimum quorum requirements for the configured topology.

Note: For EKS deployments, begin with the smallest topology that satisfies your availability requirements and validate operational workflows before expanding the deployment. At minimum, validate cluster creation, backup and restore, failover behavior, scaling, and cleanup in your own EKS environment.

Setup Checklist

Complete these steps before applying the MultigresCluster manifest:

Step 1: Install the Operator

Install the operator version that matches the Multigres release you want to run. For v0.1.0 Multigres Alpha:

kubectl apply -f https://github.com/multigres/multigres-operator/releases/download/v0.1.0/install.yaml

To use the latest available release:

kubectl apply -f https://github.com/multigres/multigres-operator/releases/latest/download/install.yaml

Note: For reproducible deployments, prefer a versioned release URL over latest.

Wait for the operator to become ready:

kubectl get pods -n multigres-operator

Image Selection

The MultigresCluster example below intentionally does not set spec.images. When image fields are omitted, the installed operator uses its default component images for that operator release.

Use the matching operator release for the Multigres release you want to test. Only set spec.images when you deliberately need to override the release defaults, for example while testing a custom build.

Optional image override shape:

spec:
  images:
    multigateway: ghcr.io/multigres/multigres:<tag-or-digest>
    multiorch: ghcr.io/multigres/multigres:<tag-or-digest>
    multipooler: ghcr.io/multigres/multigres:<tag-or-digest>
    multiadmin: ghcr.io/multigres/multigres:<tag-or-digest>
    multiadminWeb: ghcr.io/multigres/multiadmin-web:<tag-or-digest>
    postgres: ghcr.io/multigres/pgctld:<tag-or-digest>

After the cluster is created, you can inspect the actual images selected by the operator:

kubectl get pods -o jsonpath='{range .items[*]}{.metadata.name}{" "}{range .spec.containers[*]}{.name}{"="}{.image}{" "}{end}{"\n"}{end}'

Step 2: Choose a Namespace

Create a namespace for the Multigres cluster:

kubectl create namespace multigres-demo

Use the same namespace for the PostgreSQL password secret, backup service account, and MultigresCluster resource. Set it as your default context namespace:

kubectl config set-context --current --namespace=multigres-demo

Step 3: Configure Storage

Multigres poolers require persistent volumes. On EKS, install and configure the AWS EBS CSI driver before creating a Multigres cluster. Verify that dynamic volume provisioning is available:

kubectl get storageclass

The reference manifest uses a gp3 StorageClass named multigres-gp3. If your cluster already has a suitable default StorageClass, you can omit the explicit storage class from the manifest.

Step 4: Confirm Zone Labels

Multigres cells map to Kubernetes topology labels. On EKS, verify that nodes expose AWS zone IDs:

kubectl get nodes -L topology.k8s.aws/zone-id,topology.kubernetes.io/zone

Use the topology.k8s.aws/zone-id values for the Multigres zoneId fields in the manifest. The supported zones for the shared demo cluster are:

Step 5: Prepare S3 Backups

Create or select an S3 bucket for backups. Use a unique keyPrefix for each cluster if you plan to recreate clusters or run multiple clusters in the same bucket.

The backup service account must be able to read, write, list, and delete objects under the configured backup prefix. On EKS, use IAM Roles for Service Accounts (IRSA) to grant the Kubernetes service account access to S3.

Create the service account:

kubectl create serviceaccount multigres-backup

If using IRSA, annotate the service account with the IAM role that has S3 access:

kubectl annotate serviceaccount multigres-backup \
  eks.amazonaws.com/role-arn=arn:aws:iam::<account-id>:role/<multigres-backup-role>

At minimum, the backup identity needs the following S3 permissions:

• s3:ListBucket and s3:GetBucketLocation on the bucket, scoped to the configured prefix
• s3:GetObject, s3:PutObject, s3:DeleteObject on objects under the prefix

Example IAM policy:

{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Effect": "Allow",
      "Action": ["s3:ListBucket", "s3:GetBucketLocation"],
      "Resource": "arn:aws:s3:::your-backup-bucket",
      "Condition": {
        "StringLike": {
          "s3:prefix": ["multigres-demo/", "multigres-demo/*"]
        }
      }
    },
    {
      "Effect": "Allow",
      "Action": ["s3:GetObject", "s3:PutObject", "s3:DeleteObject"],
      "Resource": "arn:aws:s3:::your-backup-bucket/multigres-demo/*"
    }
  ]
}

Step 6: Create the PostgreSQL Password Secret

Create a Kubernetes secret containing the PostgreSQL superuser password:

kubectl create secret generic multigres-admin-password \
  --from-literal=password='change-this-password'

Replace change-this-password with the password you want Multigres to use for the postgres user during cluster initialization. The manifest references this secret via:

postgresPasswordSecretRef:
  name: multigres-admin-password
  key: password

Deploying the Operator on EKS

1. Configure Kubernetes Access

Update your kubeconfig to point at the EKS cluster:

aws eks update-kubeconfig \
  --name multigres-dev \
  --region us-east-1 \
  --profile eks-demo

Set your default namespace:

kubectl config set-context --current --namespace=eks-demo

Verify access:

kubectl get pods
kubectl get multigresclusters
kubectl get coretemplates,celltemplates,shardtemplates

You should see no running pods, no clusters, and the default templates present. The operator is installed and ready.

2. Create the Cluster Manifest

Create a file named demo-multi-az.yaml with the following contents. Replace placeholder values as indicated:

apiVersion: multigres.com/v1alpha1
kind: MultigresCluster
metadata:
  name: <CLUSTER_NAME>
  namespace: <NAMESPACE>
spec:
  pvcDeletionPolicy:
    whenDeleted: Delete
    whenScaled: Delete

  durabilityPolicy: AT_LEAST_2

  templateDefaults:
    coreTemplate: <CORE_TEMPLATE>
    cellTemplate: <CELL_TEMPLATE>
    shardTemplate: <SHARD_TEMPLATE>

  postgresPasswordSecretRef:
    name: <PASSWORD_SECRET_NAME>
    key: password

  backup:
    type: filesystem
    filesystem:
      path: /backups
      storage:
        size: <BACKUP_STORAGE_SIZE>

  images:
    imagePullPolicy: Always

    # Same Multigres runtime image used by all Multigres components.
    multiadmin: <ECR_REGISTRY>/multigres:<IMAGE_TAG>
    multigateway: <ECR_REGISTRY>/multigres:<IMAGE_TAG>
    multiorch: <ECR_REGISTRY>/multigres:<IMAGE_TAG>
    multipooler: <ECR_REGISTRY>/multigres:<IMAGE_TAG>

    # pgctld/Postgres image.
    postgres: <ECR_REGISTRY>/pgctld:<IMAGE_TAG>

    # Web UI image.
    multiadminWeb: ghcr.io/multigres/multiadmin-web:<MULTIADMIN_WEB_TAG>

  cells:
    - name: <CELL_NAME_A>
      zoneId: <ZONE_ID_A>
    - name: <CELL_NAME_B>
      zoneId: <ZONE_ID_B>
    - name: <CELL_NAME_C>
      zoneId: <ZONE_ID_C>

  databases:
    - name: postgres
      default: true
      backup:
        type: s3
        s3:
          bucket: <S3_BUCKET>
          region: <AWS_REGION>
          keyPrefix: <S3_KEY_PREFIX>
          serviceAccountName: <BACKUP_SERVICE_ACCOUNT>
      tablegroups:
        - name: default
          default: true
          shards:
            - name: 0-inf
              spec:
                pools:
                  default:
                    replicasPerCell: <REPLICAS_PER_CELL>
                    storage: {}
                    multipooler:
                      resources: {}
                    postgres:
                      resources: {}
                multiorch:
                  resources: {}

The manifest defines three cells, each mapped to a real AWS availability zone. AT_LEAST_2 durability means every committed write is acknowledged by at least one standby before the client receives confirmation. The operator infers resource limits, gateway configuration, and topo server sizing from the referenced templates.

3. Apply the Manifest

kubectl apply -f demo-multi-az.yaml

Watch the pods come up:

kubectl get pods -w

You should eventually see pods for:

• global-topo
• multiadmin
• multigateway (one per zone)
• multiorch (one per zone)
• pool pods (one per zone)

Within a minute the cluster should be fully running.

4. Verify the Cluster

Check the Multigres resources:

kubectl get multigresclusters
kubectl get shards

Check the pods:

kubectl get pods

A healthy cluster with minimum size should have one primary and two replicas. Run this to check directly:

PW=$(kubectl get secret <PASSWORD_SECRET_NAME> -o jsonpath='{.data.password}' | base64 -d)

for p in $(kubectl get pods -o name | grep '<CLUSTER_NAME>-postgres-default-0-inf'); do
  echo "== $p =="
  kubectl exec "$p" -c postgres -- env PGPASSWORD="$PW" \
    psql -h /var/lib/pooler/pg_sockets \
    -U postgres -d postgres -Atc \
    "select case when pg_is_in_recovery() then 'replica' else 'primary' end"
done

Expected result:

one primary
two replicas

Verify Query Serving via Multigateway

kubectl run psql-client \
  --rm -it --restart=Never \
  --image=postgres:17 \
  --env="PGPASSWORD=$(kubectl get secret <PASSWORD_SECRET_NAME> -o jsonpath='{.data.password}' | base64 -d)" \
  -- psql -h <CLUSTER_NAME>-multigateway \
  -U postgres -d postgres \
  -c "select 1, current_database(), current_user;"

Expected result:

 ?column? | current_database | current_user
----------+------------------+--------------
        1 | postgres         | postgres

5. Delete and Recreate a Cluster

Use this if you want to start over.

Delete the cluster:

kubectl delete multigrescluster <CLUSTER_NAME> --ignore-not-found

Wait until the old pods disappear:

kubectl get pods | grep <CLUSTER_NAME> || true

Delete all PVCs for the cluster, including Postgres and topo/etcd data:

kubectl get pvc -o name \
  | grep 'persistentvolumeclaim/data-<CLUSTER_NAME>-' \
  | xargs -r kubectl delete

Verify no PVCs remain:

kubectl get pvc | grep <CLUSTER_NAME> || true

Clear the S3 backup prefix before recreating a cluster with the same name and prefix:

aws s3 rm s3://<S3_BUCKET>/<S3_KEY_PREFIX> --recursive

Verify the S3 prefix is empty:

aws s3 ls s3://<S3_BUCKET>/<S3_KEY_PREFIX> --recursive

Apply the manifest again:

kubectl apply -f <MANIFEST_FILE>.yaml

6. How Applications Connect

Applications running inside the Kubernetes cluster connect to the Multigres gateway Service:

postgresql://postgres:<password>@demo-multi-az-multigateway:5432/postgres

If the application runs in another namespace, use the full Service name:

postgresql://postgres:<password>@demo-multi-az-multigateway.eks-demo.svc.cluster.local:5432/postgres

Note: *.svc.cluster.local names are Kubernetes-internal DNS names and will not resolve from your laptop shell.

7. Scaling

To start:

replicasPerCell: 1

This creates one pooler per cell — three poolers total across three AZs.

To scale, edit the MultigresCluster directly. Do not edit the generated Shard.

Example:

kubectl patch multigrescluster <CLUSTER_NAME> \
  --type=json \
  -p='[
    {
      "op": "replace",
      "path": "/spec/databases/0/tablegroups/0/shards/0/spec/pools/default/replicasPerCell",
      "value": 2
    }
  ]'

Set the value back to 1 for the basic demo shape.
